Cu products, CuCrZr, CuCr, CuNiPb, CuSi & other alloys
Our Pure Copper range includes oxygen-free & supraconductors products for the best thermal and electrical conductivity. LBA designs and manufactures a unique range of special low alloyed Copper, for very reliable components in harsh conditions, for applications requiring enhanced strength, and/or to match stringent forming and machining requirements .
Alloy Name
|
Available forms
|
Composition
|
UNS
|
AMS & ASTM
|
European Norms
|
Other norms
|
Download
|
---|---|---|---|---|---|---|---|
Alrode® Electrodes | CuCrZr | C18147 |
- | CW105C CW106C |
RWMA Class 2 |
||
Powerode® Electrodes | CuCrZr | C18150 |
- | CW105C CW106C |
RWMA class 2 |
||
Powerode+® Electrodes | CuCrZr | C18148 |
- | CW105C CW106C |
RWMA class 2 |
||
ZR16X Electrodes | CuZr | C15000 |
- | EN 12163 - EN 12167 - EN 12420 - CW120C |
RWMA class 1 |
||
Powerode® Material | CuCrZr | C18150 | - | - | RWMA class 2 | ||
Powerode+® Material | CuCrZr | C18148 | - | - | RWMA class 2 | ||
Alrode® Coils | CuCrZr | C18147 | - | - | - |
|
|
Powerode+® Coils | CuCrZr | C18148 | - | - | - |
|
|
Powerode® Coils | CuCrZr | C18150 | - | - | - |
|
|
C97 | CuNi1Pb1 | C19160 |
- | - | - | ||
C98 & C98T | CuNi1Pb1 | C19150 - C19140 |
- | - | - | ||
CRM15 | CuCr1 | C18200 | - | CW105C | - |
|
|
CRM16 | CuCr1Zr | C18150 | - | EN 12163 - EN 12165 - EN 12420 - EN 12167 - CW106C - CW105C | NFA 82100 - DIN 17666 wn 2.1293 - DIN 17672 - DIN 44759 | ||
CRM16BHP | CuCr1Zr | C18150 | - | - | - |
|
|
CRM16E | CuCr1Zr | C18100 - C18150 | - | EN 12163 - EN 12165 - EN 12420 - EN 12167 - CW106C - CW105C | NFA 82100 - DIN 17666 wn 2.1293 - DIN 17672 - DIN 44759 - BS 2874 CC 102 - MIL 19311 - RWMA class 2 | ||
CRM16EP | CuCr1Zr | C18150 | - | - | - |
|
|
CRM16HP | CuCr1Zr | C18150 | - | - | - |
|
|
Si45Z | CuSi3Fe2Zn3 | C65620 |
AMS 4616 |
- | - | ||
UC500 | CuCrZr | - | - | - | - | ||
CFE2 | CuFe2P | - | - | - | - |
|
|
CU/A1 | Cu-ETP | C11000 | ASTM B 152 | EN 12420 - CW004A | - |
|
|
CU/C1 | Cu-OF | C10200 | ASTM B 152 | EN 12420 CuDHP - CW008A | - |
|
|
CU/C2 | Cu-OFE | - | - | - | - |
|
|
CuB1 | Cu-DHP | C12200 | - | EN 12420 - CW024A | - |
|
|
CU-P2 | Cu-PHC | - | - | - | - |
|
|
Cuprofor® | CuCo0,3P | C15600 | - | - | - | ||
CuSC SupraConductor | Cu-ETP/SV | - | - | - | - |
|
